AE 504 Indicator-AE 504
- Capacity
- Selectable
The AE 504 advanced label printing indicator pairs a full range of counting applications with the ability to print fully customisable labels and barcodes into a single compact solution.
Applications
- Weighing
- Parts counting
- Checkweighing
- Check counting
- Accumulation
- Averaging
- Barcode / label printing
Features
- Backlit Display
- Tare
- Battery Power
- RS-232
- External Calibration
- Date
- Time
- Built-in Printer
- Multiple Weighing units
A sturdy, lightweight design with a sealed keypad, an internal rechargeable battery and the convenience of a built-in printer make the AE 504 advanced label printing indicator a great choice for demanding industrial settings and shipping and receiving areas. In addition to numerous weighing and counting applications, add barcodes, QR codes, pictures and custom logos to the 50mm-wide printed labels with the indicator’s integrated printer. The large, easy-to-read backlit LCD screen features 22mm-tall digits, while a color-coded numeric keypad allows quick and easy selection from 1,000+ PLUs or to manually enter tare weights, unit weights and sample sizes. NOTE: Not for use in retail applications
Features and Benefits
- Vivid, backlit LCD easily visible in any lighting conditions
- Programmable backlight can be set to "always on," "always off" or "light only when weighing"
- Colour-coded keys facilitate quick recognition of the most frequently used buttons
- RS-232 interface provides speedy connection to computers and printers
- Rugged construction stands up to industrial use
- Built-in printer can print weight, QR codes, bar codes and customized labels in numerous languages
- Rechargeable battery included for operation almost anywhere
- Programmable auto power-off to save energy
- Zero-tracking feature ensures display returns to zero reading
- Parts counting optimisation automatically refines piece weight as parts are added
- Checkweighing with audible alarm
- External calibration allows for verification and adjustment with weights
- Quick and easy configuration using the keypad
- User-selectable scale division
- 1:600,000 internal counting resolution
- A 3-year warranty means quality assured for years of use.
Technical specification
Model
AE 504
UPC: 840886105587
Metrology
Capacity
- Selectable
- Selectable
General Specifications
Weighing Units
- g, kg, lb, oz
- g, kg, lb, oz
Stabilisation Time
- 2
- 2
Interface
- RS-232
- RS-232
Calibration
- External calibration
- External calibration
Display
- Backlit LCD with 22mm high digits
- Backlit LCD with 22mm high digits
PLU Memories
- 1006
- 1006
Power
Power Supply
- 12VDC 3A adapter / Internal rechargeable battery
- 12VDC 3A adapter / Internal rechargeable battery
Battery Type
- Lead Acid
- Lead Acid
Number of batteries
- 1
- 1
Maximum Battery Life (in hours)
- 200
- 200
Operating Conditions
Operating Temperature
- 0° to 40°C / 32° to 104°F
- 0° to 40°C / 32° to 104°F
Product Information
Construction
- ABS plastic
- ABS plastic
Net Weight
- 3.5kg
- 3.5kg
Dimensions
Overall Dimensions
- 297x121x168mm
- 297x121x168mm
